Panel or Handheld: Which Red Light Therapy Device Fits Your Routine?
Published October 2026. Updated October 2026.
Quick answer
A panel lights a wider area from a set distance and is used hands free. A handheld lights a small area and goes anywhere. Pick the panel if you use a fixed spot at home and want one position per session. Pick the handheld if you move around, travel, or only need a small area. The AWA panels (FX500 and FX300) publish irradiance by distance. The handheld pages do not, so compare them with care.
The real trade: coverage against portability
Every difference between these two formats comes from one design choice. A panel is a flat surface of LEDs that you place at a distance, so it lights a wide patch at once. A handheld puts a small LED head close to one spot, so it lights a small patch and you move it yourself.
That choice decides setup, storage, where you can use it and how much of your routine it will take. It does not make one format better in general. It makes one better for a specific routine.
Side by side, using what the AWA pages list
| Factor | Panel (FX300, FX500) | Handheld (3 in 1 Torch) |
|---|---|---|
| Light area per position | A wide patch from one position | A small patch, so you move it |
| Hands | Free once it is mounted or standing | One hand holds it |
| Power | Corded, AC 100 to 240V | Rechargeable |
| Working distance | About 6 to 12 inches per the page | The Torch page does not list one here. Follow the manual |
| Setup | Door hook, hanging kit or foldable stand | None |
| Wavelengths | 660nm and 850nm | Torch red, near infrared and blue |
| Published irradiance by distance | Yes, on this site | Not published here for the handheld devices |
The last row matters for comparison. Our irradiance specs give exact figures for the FX300 and FX500 at set distances. Without a number at a stated distance for a handheld, you cannot compare its output with a panel. Ask for it, and see what irradiance means on a spec sheet.
Worked example: how many positions to cover an area?
This is arithmetic with example numbers for arithmetic only. It is not a session recommendation and not an AWA spec.
Say you want to light an area of 400 square centimeters. Suppose a handheld head covers 24 square centimeters at once (an invented number). Then 400 / 24 is about 17 positions. If you spent 1 minute in each, the pass would take about 17 minutes of moving the device.
Now suppose a panel lights the whole 400 square centimeters from one position. The whole area is covered while you sit still, and the clock is just the session time your manual sets.
| Format (example) | Positions for 400 cm² | Hands needed | Time cost of repositioning |
|---|---|---|---|
| Handheld, 24 cm² per position | About 17 | One hand throughout | You carry the time cost yourself |
| Panel, whole area in one position | 1 | None after setup | Nearly none |
The point is not that one is faster. It is that a small head needs repositioning, and a panel needs space and a mount. Count the cost that matters in your day.
Match the format to your routine
| Your situation | Leans toward | Why |
|---|---|---|
| You use one fixed spot at home most days | Panel | Mount it once and every session starts in seconds |
| You want to cover a larger area in one position | Panel | One position lights a wide patch |
| You travel often or work from different rooms | Handheld | Rechargeable and small. See devices for travel |
| You only need a small, specific area | Handheld | Matches the area without setup |
| You share a small room and have little wall space | Handheld or door mounted panel | Check depth with our home use checklist |
| You want hands free sessions | Panel, belt or slippers | Compare panel, mask and belt formats |
Can you own both?
Many households do. A panel stays in one room for longer sessions at a fixed distance. A handheld goes in a bag. If you are choosing only one, think about the place where you will really use it, not the place you imagine using it.
If you want a panel, the FX500 is listed with a foldable stand and remote, and the FX300 with a hanging kit and rope. Our FX300 vs FX500 guide covers the panel choice. For the handheld side, browse the handheld devices collection.
What to ask before buying either
- Irradiance at a stated distance. Total watts or LED counts do not tell you the output on your skin.
- Wavelengths in exact numbers. Look for figures such as 660nm and 850nm, not a loose range.
- Power and runtime. For rechargeables, ask how long a charge lasts and how you charge it.
- What is in the box. Goggles, a stand, hooks, a remote and a cable change the real price.
- Return window and warranty. The AWA pages list a 60 day money back guarantee. Confirm the terms on the site before you order.
Common mistakes
- Comparing a handheld and a panel by LED count. More LEDs on a small head does not equal more light on your skin at distance.
- Buying a panel without checking depth in front of the mount.
- Buying a handheld for a large area and then skipping sessions because repositioning takes too long.
- Assuming every format publishes the same specs. Compare only the numbers both list at the same distance.
- Ignoring eye safety. Use the goggles or eye protection your manual calls for. Read the eye protection notes in your manual.
- Using this guide as session advice. Time and distance come from your device manual.
Before you use any light device: read the label, follow the device manual, and use eye protection as directed. Ask a doctor first if you have a medical condition, take medications, are pregnant, or have light sensitivity.
Related guides
- AWA FX300 and FX500 irradiance specs
- Red light therapy formats guide
- What irradiance means
- Home use buyer's checklist
Device pages
Read the full page and label for each device before you use it: AWA FX500 panel, AWA 3 in 1 Torch. You can also browse the AWA handheld devices.
Frequently asked questions
Is a panel better than a handheld?
Neither is better in general. A panel lights a wider patch from a set distance and works hands free. A handheld is small and portable but lights a small patch. Choose by routine and space.
Do handheld devices publish irradiance?
On this site, irradiance by distance is published for the FX300 and FX500 panels only. For any handheld, ask for irradiance at a stated distance before you compare it with a panel.
Can I use a handheld on a large area?
You can move it across an area, but each position covers a small patch. The worked example above uses invented numbers to show how positions add up.
Which one is easier to travel with?
A rechargeable handheld is usually easier to pack. Check airline rules for batteries before you fly.
How long should a session be?
Your device manual sets session time and distance. This guide explains formats and arithmetic only. Ask a doctor about any personal health question.
Sources
- FDA: General Wellness policy for low risk devices. The agency's guidance dated January 2026 on its compliance policy for general wellness products. It is a policy document, not a statement about any one device.
- FDA: Laser Products and Instruments. Describes the FDA laser hazard classes I to IV and notes that LEDs differ from laser diodes and are not subject to the federal laser product performance standard.
Regulatory note: select devices carry FDA 510(k) clearance for specific, limited uses. Most light devices are sold as general wellness products. Read each product page and label.
How we create this guide
AWA sells red light therapy devices. We write these guides to explain how devices work and how to choose and use one. This is general information, not medical advice. Read each product page and label. See our editorial standards.
